Vertical Outlet Drain without Flange
NV Series

1.Quickly slop;Vertical outlet
2.Easy Installation, with Adjustable Legs
3.Safe installation and use, with smooth sides
4.Save the time of construction , using the drainage of same gradient ,construction of simple ,maintain tile integrity and beautiful appearance
5.Security increased ,it is atrouble free access for some people whose action is inconvenience as it do not need the stone to separate dry and wet areas

Technical drawings
Item no. NV-300 NV-400 NV-500 NV-600 NV-700 NV-800 NV-900 NV-1000 NV-1200 NV-1500 NV-2000 NV-2500 NV-3000
L(mm) 300 400 500 600 700 800 900 1000 1200 1500 2000 2500 3000
L(inch) 12'' 16'' 20'' 24'' 28'' 32'' 36'' 40'' 48'' 60'' 80'' 100'' 120''
W(mm) 70/80/100 70/80/100 70/80/100 70/80/100 70/80/100 70/80/100 70/80/100 70/80/100 70/80/100 70/80/100 70/80/100 70/80/100 70/80/100
H(mm) 65 65 65 65 65 65 65 65 65 65 65 65 65
Outlet(mm) 40/50 40/50 40/50 40/50 40/50 40/50 40/50 40/50 40/50 40/50 40/50 40/50 40/50
Material Stainless Steel 304/316L
